1. Download and Install
- Go to the Download section and click "Download Setup (.exe)" for Windows.
- Once downloaded, double-click
metabodesk_setup.exe to start the installer.
- Follow the installation wizard: accept the license agreement (CC BY-NC-ND 4.0), choose your preferred installation folder (default:
C:\Program Files\MetaboDesk), and click Install.
- Wait for the installation to complete. This may take 1-2 minutes depending on your system.
- After installation completes, launch MetaboDesk from the Start Menu or desktop shortcut.
System Requirements: Windows 10/11 (64-bit), 4 GB RAM minimum, 500 MB disk space.
2. Open a Model
- Click "Open SBML..." in the top toolbar.
- Navigate to your SBML file (e.g.,
e_coli_core.xml) and click Open.
- The model will load and you'll see a summary: number of reactions, metabolites, and genes.
- The status bar at the bottom will show "Model loaded successfully" with statistics.
Where to get models: Download curated genome-scale models from
BiGG Models or
BioModels. Popular choices include
e_coli_core (small, good for learning) and
iML1515 (full E. coli model).
3. Understanding Analysis Types
MetaboDesk offers multiple analysis methods. Here's what each one does:
📊 Flux Balance Analysis (FBA)
FBA is the core method for predicting metabolic fluxes. It uses linear programming to maximize an objective function (usually biomass/growth) subject to stoichiometric constraints and reaction bounds.
Example: Load e_coli_core, run FBA, and see the predicted growth rate (~0.87 h⁻¹) along with flux values for all 95 reactions.
⚡ Parsimonious FBA (pFBA)
pFBA first optimizes for maximum growth (like FBA), then minimizes total flux while maintaining that growth. This yields more realistic, sparse flux distributions.
Use case: When you want to identify the most efficient pathways without unnecessary flux loops.
📈 Flux Variability Analysis (FVA)
FVA determines the minimum and maximum possible flux through each reaction while maintaining optimal (or near-optimal) growth. Reactions with wide ranges are flexible; narrow ranges indicate constrained reactions.
Example: Run FVA to identify which reactions are "blocked" (min=max=0) and which have flexibility for metabolic engineering.
🧬 Single Gene Deletion (SGD)
SGD systematically knocks out each gene one at a time and measures the impact on growth. Essential genes cause lethality (growth = 0) when deleted.
Example: In e_coli_core, deleting b2779 (ENO enzyme) eliminates growth because it's essential for glycolysis.
🔗 Double Gene Deletion (DGD)
DGD tests all pairwise gene knockouts to find synthetic lethal pairs—genes that are individually non-essential but lethal when both are deleted.
Use case: Identifying backup pathways and redundancy in metabolism.
⚗️ Single Reaction Deletion (SRD)
Similar to SGD but deletes reactions instead of genes. Useful when gene-protein-reaction associations are incomplete.
📉 Robustness Analysis
Varies the bounds of a specific reaction (e.g., glucose uptake) over a range and tracks how the objective changes. Shows sensitivity and identifies critical thresholds.
Example: Vary EX_glc__D_e from 0 to -20 mmol/gDW/h and observe how growth rate responds. You'll see a linear increase up to saturation.
🎯 Production Envelope
Shows the trade-off between biomass and a target product. As you force more production of a metabolite, growth typically decreases. The envelope shows all feasible combinations.
Example: Plot growth vs. ethanol production to see the maximum theoretical yield while maintaining cell viability.
🎲 Flux Sampling
Uses Monte Carlo sampling (ACHR algorithm) to explore the entire feasible flux space. Returns distributions (mean, std, min, max) for each reaction.
Use case: When you want probabilistic insights rather than a single optimal solution.
4. Run Your First Analysis
- With a model loaded, select "FBA" from the Analysis dropdown.
- Click "Run Analysis".
- Wait for computation (usually < 1 second for FBA).
- View results in the Results tab: objective value, flux chart, and detailed table.
5. Review and Filter Results
- Use the search boxes to filter by reaction ID.
- Set delta threshold to show only significant flux changes.
- Click table headers to sort by column.
- Double-click cells to see full details in a popup.
6. Export Results
Each analysis tab has an "Export CSV" button. Click it, choose a save location, and your results are exported for further analysis in Excel, Python, or R.
7. Modify the Medium (Exchange Reactions)
- Go to the Medium tab.
- Search for exchange reactions (e.g.,
EX_glc__D_e for glucose).
- Double-click the Lower/Upper bound cells to edit uptake limits.
- Negative lower bound = uptake allowed; zero = no uptake.
- Use built-in presets: "Minimal M9" or "Rich LB" for common media.
Example: To simulate anaerobic growth, set EX_o2_e lower bound to 0 (no oxygen uptake).
8. Gene Knockouts (Manual)
- Go to the Gene knockout tab.
- Search for the gene (e.g.,
b0720).
- Select it and click "Add knockout".
- The knockout list shows all active knockouts.
- Run FBA to see how growth is affected.
- Use "Clear knockouts" to reset.
9. Overexpression
- Go to the Overexpression tab.
- Search for a reaction (e.g.,
PFK for phosphofructokinase).
- Set the overexpression factor (e.g., 2x doubles the upper bound).
- Click "Add overexpression".
- Run analysis to observe effects on metabolism.
10. Network Map Visualization
- Go to the Map tab.
- Search: Enter a reaction/metabolite ID to focus on.
- Depth: How many neighbors to show (1-5).
- Flux threshold: Hide reactions with |flux| below threshold.
- View mode: Color by flux magnitude, gene KO impact, or FVA bounds.
- Click "Render Map" to generate.
- Click nodes to see details. Use toolbar to zoom/pan.
- Export as image or CSV using the buttons.
11. Model Editor (Patch-Based)
The Model Editor lets you modify models without altering the original SBML file. Changes are tracked as a "patch" that can be applied, saved, or exported.
Add Metabolites
- Go to Model Editor → Metabolites sub-tab.
- Enter metabolite ID (e.g.,
new_met_c), name, formula, and compartment.
- Click "Add Metabolite".
Add Genes
- Go to Model Editor → Genes sub-tab.
- Enter gene ID and name.
- Click "Add Gene".
Add or Modify Reactions
- Go to Model Editor → Reactions sub-tab.
- Enter reaction ID, name, equation (e.g.,
atp_c + h2o_c -> adp_c + pi_c), and bounds.
- Optionally add GPR (gene-protein-reaction rule).
- Click "Add/Update Reaction".
Disable or Delete Reactions
- Go to Model Editor → Disable/Delete sub-tab.
- Search for the reaction to remove.
- Use "Disable" (sets bounds to 0) or "Delete" (removes entirely).
View and Export Patch
- Go to Model Editor → Patch sub-tab to see all changes as JSON.
- Copy or save the patch for later.
Export Modified SBML
- Go to Model Editor → Export SBML sub-tab.
- Click "Export as SBML" to save the modified model as a new file.
12. Tools: memote (Model Quality)
memote is an automated tool that evaluates genome-scale metabolic models for quality, completeness, and MIRIAM annotation compliance.
- Go to the Tools tab.
- Make sure tools are installed: click "Check tools". If missing, click "Repair tools".
- Load your SBML model.
- Click "Run memote report (current model)".
- Wait for the analysis (can take 1-5 minutes depending on model size).
- A detailed HTML report opens in your browser with scores for:
- Stoichiometry consistency
- Mass/charge balance
- Annotation completeness (KEGG, ChEBI, UniProt, etc.)
- Biomass composition
- And many more checks...
Tip: Use memote reports to identify issues before publishing your model.
13. Tools: CarveMe (Model Reconstruction)
CarveMe reconstructs genome-scale metabolic models from annotated genome files (protein FASTA or GenBank).
- Go to the Tools tab.
- Ensure tools are installed ("Check tools").
- Click "Run CarveMe (genome → SBML)".
- Select your input file (protein FASTA or GenBank).
- Choose output location for the generated SBML.
- Wait for reconstruction (can take 5-30 minutes depending on genome size).
- The reconstructed model is saved and can be opened in MetaboDesk.
Use case: Quickly generate a draft model for a new organism from its genome annotation.
14. Saving and Loading Scenarios
- Use File → Save Scenario to save current settings (knockouts, overexpressions, medium changes).
- Use File → Load Scenario to restore a saved configuration.
- Recent scenarios appear in the File menu for quick access.
15. Keyboard Shortcuts
Ctrl+O — Open SBML fileCtrl+R — Run analysisCtrl+S — Save scenarioCtrl+Z — UndoCtrl+Y — Redo
Troubleshooting
- Model won't load: Ensure it's a valid SBML Level 3 file. Try opening in COBRApy first.
- Analysis stuck: Large models (>5000 reactions) may take longer. Check the status bar.
- memote/CarveMe not working: Go to Tools tab and click "Repair tools" to reinstall dependencies.
- Solver errors: Try switching to a different solver (Auto, glpk, or highs) in the toolbar.
Need more help? Check the Tools tab log output for detailed error messages, or contact support.
